A-61981 20 April 2022 47
Changing print
positions
You will need to remove the printing location screw if you want to use 11 print
positions. If you leave the screw in place, only 9 print positions will be
available.
The horizontal print position must be changed manually.
1. Open the printer door.
2. Slide the printer carrier to the desired printing position.
IMPORTANT: When changing print positions, it is important to verify that
the printer carrier is securely in a printing (detent) position.
When you slide the printer carrier into a printing position,
you will be able to feel the printer carrier click into place.
3. Close the printer door.
NOTE: The print location indicators at the edge of the transport can be
used as a guide to verify your horizontal print position.
print location indicators
