14 KODAK CAROUSEL® Slide Projector
Operation
Choosing a Curved-
or Flat-Field Lens
The lens you select depends on how you use your projector and what type of
slide mount you use. So that you may choose the lens that best meets your
needs, we do not include a lens with the projector.
To obtain the best results of a projected image, insert slides with the emulsion
side toward the projection lens, slide curve toward the light source.
A flat-field lens works best for:
• general home projection
• glass mounts
• plastic mounts
• mixed mounts
• non-embossed cardboard mounts
• rear-projection applications
• duplicated slides
A curved-field lens works best for:
• embossed cardboard mounts
(Embossed mounts have beveled edges around the aperture. Kodak
Premium Processing and Kodak Processing labs provide embossed
mounts.)
Lens Focal Length/
Projector Distance
Use the illustration on the following page to help determine the lens focal
length and projector distance.
