22 KODAK CAROUSEL® Slide Projector
Maintenance
Cleaning the Condenser, Heat-Absorbing Glass, and
Mirror
To clean the condenser, heat-absorbing glass, or mirror,you must disassemble
the lamp module.
Slide the power switch to Off and
unplug the projector. Allow the
projector to cool about 10 minutes.
Push the lamp-module release
button and remove the lamp
module.
Use a torx-head screwdriver to
remove the screw.
Using a flat-blade screwdriver, apply ample
pressure to release each of the metal tabs.
Lift off the top of the lamp module.
