Koden RA40C - Page 100

80
(3) Fuse
The fuse is built in
the power supply cable.
If the fuse appears to be
blown, check the fuse. If
blown, replace it
following the procedure
shown in Fig.6-2.
Note: Before maintenance of scanner, you can hang a radome(upper) using cord
through hole as follows.
Fig. 6-3 Method for replacing fuse
Push
Power supply cable
Wire(White)
Turn counterclockwise
and pull
Fuse
Spring
Push and turn clockwise
Replace new fuse
To dis
p
la
y
unit
Fig. 6-2 Method for replacing fuse
Fixing screw
Hole
A: Top view
Cord
Cord
A
Radome(Upper)
Radome(bottom)
