TP-6196 10/09 43Section 4 ADC 2100 and DC 2200 Controllers
or
To set the engine data input type to Ed05.
To enter battery voltage selection mode.
or
To toggle between 12 and 24 VDC. Set this
parameter to 12 VDC.
To enter communications selection mode.
or
To set the communications parameter to
Cn00.
To enter SAVE mode. Go to Figure 4-10.
E d 0 5
Pressing the up arrow key at the Adnc display (See Figure 4-8) puts you into
the Advanced Configuration Mode.
Press:
B t 1 2
C n 0 0
S A V E
Note: Be sure to save your settings before exiting the configuration mode. The controller reverts to
the last saved settings when the master switch is moved to the OFF/RESET position.
Note: Be sure to save your settings before exiting the configuration mode. The controller reverts to
the last saved settings when the master switch is moved to the OFF/RESET position.
Figure 4-9 Advanced Configuration Mode (engine data input types, battery voltage, and engine
communications)
To save changes.
To discard changes without saving.
or
* X in the runtime hours display above denotes any number from 0 to 9.
S A V E
Y E S
Now move the master switch to OFF/RESET.
n o
There are 3 options when the display says SAVE:
Press:
x x xx
or
To return to the first parameter, system voltage/frequency
Uu, to check or change settings before saving. See
Figure 4-8.
U u 0 1
Yes or no flashes when the up or down arrow is pressed
and then the controller exits the configuration mode. The
display returns to the runtime hours. *
Figure 4-10 Save Mode (after configuring generator set parameters)
