Kohler 20RESC User Manual

TP-6805 8/15 59Section 4 Controller
Volts L1--L2:
240 V
Volts L2--L3:
240 V
Volts L3--L1:
240 V
Generator ---->
Metering
Reset
Calibration
<---- Return
Reset
Calibration? No
Volts:
240V
Three-phase Single-phase
tp6811
Reset
Calibration? Yes
Frequency:
60.0 Hz
Frequency:
60.0 Hz
1. Press Select when the voltage is
displayed. The voltage flashes.
2. Press the Up or Down arrow
button to change the setting.
3. Press the Select button to save the
setting.
4. Press the down arrow button to
move to the next menu.
Calibrate
Calibrate
Calibrate
Calibrate
Note: Pressing select when Reset Calibration: Yes is displayed will discard
the changes and reset the calibration to the original settings.
To Calibrate Voltage:
Figure 4-18 Voltage Calibration

Kohler 20RESC Specifications

General

Rated Output (Gasoline)	20 kW
Rated Output (LPG)	18 kW
Voltage	120/240 V
Frequency	60 Hz
Fuel Type	Gasoline, LPG, Natural Gas
Starting System	Electric
Warranty	5 years limited
Dimensions	48.5 in L x 29 in H
