132 TP-6694 6/22
6.1.1 Battery Chargers
The following battery chargers are available for the generator sets covered in this manual:
6 amp, 12 volt battery charger
10 amp battery charger with alarms (meets NFPA requirements)
Refer to the documentation provided with the battery charger for installation and operation instructions.
Figure 61 Battery Chargers
6.1.2 Battery Charger Kit with Alarm Option
The battery charger with alarm option provides battery charging to the engine starting battery(ies) and connects to the controller
for fault detection. Battery chargers for 12- or 24-volt models are available as a generator set accessory. See Figure 62 and
Figure 63 for battery connections.
Note:
On charger GM87448, the Battery Charger Fault is communicated through CAN communication and the connection on TB1 is
not used.
Figure 62 Battery Charger Connections
