TP-7102 3/20 35Section3 RDC2ControllerOperation
3.8 Overview Menu
Overview - - >
1.2 h
Active Alert
(if any)
tp6809
Genset Status
Standby
Voltage: 240V
Freq: 60.0Hz
Engine: 95F
Oil: 40 PSI
Battery
13.4V
Engine Runtime:
27.4 h
Date: 01Mar2018
Time: HR:MNpm
Next Exercise:
09:00p 09Mar2018
Next Maintenance:
150 h or Jan2019
SW Version:
1.01
<- - Return
Figure 3-8 Overview Menu
3.9 Engine Metering Menu
The engine metering menu displays engine status
information as shown in Figure 3-9. This menu displays
status information only. No settings can be changed
from this menu.
tp6810
Eng Speed:
1800 RPM
Coolant Temp:
73 F
Battery:
13.4 V
<- - Return
Engine - - >
Metering
Oil Pressure:
40 PSI
Oil Temp:
73 F
Figure 3-9 Engine Metering Menu
