TP-6774 2/14a30 Section 5 Cooling System
13. Dip the heat exchanger tube into a solution of
90% water and 10% hydrochloric acid. Use gloves
and goggles.
14. Rinse the heat exchanger tube in clean water. See
Figure 5-10.
Figure 5-10 Rinse Heat Exchanger Tube
Note: Replace any damaged O-rings, seals and/or
thermostat valve seals.
15. Reinstall the heat exchanger tube and O-rings.
See Figure 5-11.
Figure 5-11 Reinstall Heat Exchanger
16. Reassemble the O-ring and front cover and tighten
the screws. See Figure 5-12 and Figure 5-13.
Figure 5-12 Reinstall the O-ring and Front Cover
Figure 5-13 Tighten the Front Cover Screws
17. Fit the circlip and flange back into position. See
Figure 5-14.
Figure 5-14 Heat Exchanger’s Circlip
