Specifi cations
962 690 13 Rev. A KohlerEngines.com
Engine Dimensions with Low-Profi le Air Cleaner - Flywheel Side
A
B
C
D
E
F
G
H
I
J
K
L
M
K
N
O
P
Q
R
S
M
L
T
U
V
W
X
A 483.0 mm (19.02 in.) B 370.9 mm (14.60 in.) C Lifting Point D
106.0 mm (4.17 in.)
Lifting Point
E 79.5 mm (3.13 in.) F 136.2 mm (5.36 in.) G
68.6 mm (2.70 in.)
Spark Plug Boot
Removal
H Oil Fill
I
33.3 mm (1.31 in.)
Spark Plug Removal
J
32.2 mm (1.27 in.)
Spark Plug Boot
K 37° L
389.6 mm (15.34 in.)
Spark Plug Boot
Removal
M
381.1 mm (15.00 in.)
Spark Plug Removal
N Mounting Hole "A" O 106.0 mm (4.17 in.) P 232.0 mm (9.13 in.)
Q Center Line Engine R
8 X Ø 10.7 mm (0.42 in.)
Thru Mounting Holes
S
Engine Mounting
Surface
T
572.5 mm (22.54 in.)
Lifting Point
U
32.7 mm (1.29 in.)
Spark Plug Boot
V
34.6 mm (1.36 in.)
Spark Plug Removal
W
70.0 mm (2.76 in.)
Spark Plug Boot
Removal
X
Mechanical Fuel
Pump
