Page #10 background image
10
Specications
KohlerEngines.com 32 690 01 Rev. D
CLEARANCE SPECIFICATIONS
3
SV710
SV810
SV715 SV720
SV820
SV725 SV730
SV830
SV735 SV740
SV840
Crankshaft
End Play (free) 0.070/0.590 mm (0.0028/0.0230 in.)
Bore (in crankcase)
New
Max. Wear Limit
40.965/41.003 mm (1.6128/1.6143 in.)
41.016 mm (1.6148 in.)
Bore (in oil pan)
New 40.974/40.987 mm (1.6131/1.6136 in.)
Crankshaft Bore (in oil pan)-to-Crankshaft Running
Clearance
New
0.039/0.074 mm (0.0015/0.0029 in.)
Flywheel End Main Bearing Journal
O.D. - New
O.D. - Max. Wear Limit
Max. Taper
Max. Out-of-Round
40.913/40.935 mm (1.6107/1.6116 in.)
40.84 mm (1.608 in.)
0.022 mm (0.0009 in.)
0.025 mm (0.0010 in.)
Oil Pan End Main Bearing Journal
O.D. - New
O.D. - Max. Wear Limit
Max. Taper
Max. Out-of-Round
40.913/40.935 mm (1.6107/1.6116 in.)
40.84 mm (1.608 in.)
0.022 mm (0.0009 in.)
0.025 mm (0.0010 in.)
Connecting Rod Journal
O.D. - New
O.D. - Max. Wear Limit
Max. Taper
Max. Out-of-Round
35.955/35.973 mm (1.4156/1.4163 in.)
35.94 mm (1.415 in.)
0.018 mm (0.0007 in.)
0.025 mm (0.0010 in.)
T.I.R.
PTO End, Crank in Engine
Entire Crank, in V-Blocks
0.279 mm (0.0110 in.)
0.10 mm (0.0039 in.)
Cylinder Bore
Bore I.D.
New
Max. Wear Limit
Max. Out-of-Round
Max. Taper
83.031/83.006 mm (3.2689/3.2679 in.)
83.069 mm (3.2704 in.)
0.12 mm (0.0047 in.)
0.05 mm (0.0020 in.)
Cylinder Head
Max. Out-of-Flatness 0.076 mm (0.003 in.)
Governor
Governor Cross Shaft-to-Crankcase Running Clearance 0.025/0.126 mm (0.0009/0.0049 in.)
Cross Shaft O.D.
New
Max. Wear Limit
7.949/8.000 mm (0.3129/0.3149 in.)
7.936 mm (0.3124 in.)
Governor Gear Shaft-to-Governor Running Clearance 0.015/0.140 mm (0.0006/0.0055 in.)
Gear Shaft O.D.
New
Max. Wear Limit
5.990/6.000 mm (0.2358/0.2362 in.)
5.977 mm (0.2353 in.)
3
Values are in Metric units. Values in parentheses are English equivalents.
7
Measure 6 mm (0.236 in.) above bottom of piston skirt at right angles to piston pin.
