Kohler Courage PRO User Manual

9
Specications
32 690 01 Rev. D KohlerEngines.com
TORQUE SPECIFICATIONS
3,5
SV710
SV810
SV715 SV720
SV820
SV725 SV730
SV830
SV735 SV740
SV840
Starter Assembly
Thru Bolt
Inertia Drive
Solenoid Shift
4.5-5.7 N·m (40-50 in. lb.)
5.6-9.0 N·m (49-79 in. lb.)
Mounting Screw 15.3 N·m (135 in. lb.)
Brush Holder Mounting Screw 2.5-3.3 N·m (22-29 in. lb.)
Stator
Mounting Screw 6.2 N·m (55 in. lb.)
Valve Cover
Fastener 6.2 N·m (55 in. lb.)
CLEARANCE SPECIFICATIONS
3
SV710
SV810
SV715 SV720
SV820
SV725 SV730
SV830
SV735 SV740
SV840
Camshaft
End Play (with shim) 0.076/0.127 mm (0.0030/0.0050 in.)
Running Clearance 0.025/0.063 mm (0.0010/0.0025 in.)
Bore I.D.
New
Max. Wear Limit
20.000/20.025 mm (0.7874/0.7884 in.)
20.038 mm (0.7889 in.)
Bearing Surface O.D.
New
Max. Wear Limit
19.962/19.975 mm (0.7859/0.7864 in.)
19.959 mm (0.7858 in.)
Connecting Rod
Connecting Rod-to-Crankpin Running Clearance
New
Max. Wear Limit
0.030/0.055 mm (0.0012/0.0022 in.)
0.070 mm (0.0028 in.)
Connecting Rod-to-Crankpin Side Clearance 0.26/0.63 mm (0.0102/0.0248 in.)
Connecting Rod-to-Piston Pin Running Clearance 0.015/0.028 mm (0.0006/0.0011 in.)
Piston Pin End I.D.
New
Max. Wear Limit
17.015/17.023 mm (0.6699/0.6702 in.)
17.036 mm (0.6707 in.)
Crankcase
Governor Cross Shaft Bore I.D.
New
Max. Wear Limit
8.025/8.075 mm (0.3159/0.3179 in.)
8.088 mm (0.3184 in.)
3
Values are in Metric units. Values in parentheses are English equivalents.

Kohler Courage PRO Specifications

General

Governor Type	Mechanical
Compression Ratio	8.5:1
Fuel Type	Gasoline
Cooling System	Air Cooled
Ignition System	Electronic
Starting System	Electric start (optional recoil start)
Lubrication System	Splash lubrication
