Specications
32 690 01 Rev. D KohlerEngines.com
GENERAL SPECIFICATIONS
3.6
SV710
SV810
SV715 SV720
SV820
SV725 SV730
SV830
SV735 SV740
SV840
Bore 83 mm (3.27 in.)
Stroke 67 mm (2.64 in.)
Displacement 725 cc (44 cu. in.)
Oil Capacity (rell) 1.6-1.8 L (1.7-1.9 qt.)
Maximum Angle of Operation (@ full oil level)
4
25°
TORQUE SPECIFICATIONS
3,5
SV710
SV810
SV715 SV720
SV820
SV725 SV730
SV830
SV735 SV740
SV840
Blower Housing and Sheet Metal
M4 HI-LO Screw 2.8 N·m (25 in. lb.)
M5 Fasteners 6.2 N·m (55 in. lb.) into new hole
4.0 N·m (35 in. lb.) into used hole
M6 Fasteners 10.7 N·m (95 in. lb.) into new hole
7.3 N·m (65 in. lb.) into used hole
Carburetor
Mounting Nut 6.2-7.3 N·m (55-65 in. lb.)
Connecting Rod
Cap Fastener (torque in increments) 11.3 N·m (100 in. lb.)
Crankcase
Breather Assembly
Inner Cover Fastener
Outer Cover Stud
Outer Cover Hex Nut
10.7 N·m (95 in. lb.) into new hole
7.3 N·m (65 in. lb.) into used hole
6.2 N·m (55 in. lb.) into new hole
4.0 N·m (35 in. lb.) into used hole
1.3 N·m (11.5 in. lb.)
Oil Drain Plug 13.6 N·m (10 ft. lb.)
ENGINE IDENTIFICATION NUMBERS
Kohler engine identication numbers (model, specication and serial) should be referenced for efcient repair,
ordering correct parts, and engine replacement.
Model . . . . . . . . . . . . . . . . . . . . . SV710
Courage Engine
Vertical Shaft
Numerical Designation
Specication . . . . . . . . . . . . . . . SV710-0001
Serial . . . . . . . . . . . . . . . . . . . . . 3923500328
Year Manufactured Code Factory Code
Code Year
39 2009
40 2010
41 2011
3
Values are in Metric units. Values in parentheses are English equivalents.
4
Exceeding maximum angle of operation may cause engine damage from insufcient lubrication.
5
Lubricate threads with engine oil prior to assembly.
6
Any and all horsepower (hp) references by Kohler are Certied Power Ratings and per SAE J1940 & J1995 hp
standards. Details on Certied Power Ratings can be found at KohlerEngines.com.
