Kohler Courage XT-6 Service Manual

8.5
Section 8
Disassembly
8
ȱ Śǯȱ ȱěȱȱȇȱȱǰȱȱǰȱ
and spacer gasket, noting the sequence. See
Figure 8-16.
Remove Carburetor with Choke
1. Squeeze the hose clamp and slide it and the fuel
ȱěȱȱǯȱȱȱŞȬŗŝǯ
Figure 8-16. Carburetor Gasket Sequence.
Figure 8-17. Disconnecting Fuel Line.
Remove Carburetor Assembly
NOTE: Ensure the fuel tank is empty by running the
engine until it stops, and is completely out of
fuel.
Remove Choke-less Carburetor
1. Squeeze the hose clamp and slide it and the fuel
ȱěȱȱǯȱȱȱŞȬŗřǯȱ
ȱ Řǯȱ ȱȱĴȱȱȱĴǰȱȱ
ȱȱȱȱȱěȱȱǯȱȱ
Figure 8-15.
ȱ řǯȱ ȱȱĴȱȱȱȱȱǯ
Gently push the rod and spring linkages up
ȱȱȱȱȱĴȱǯȱȱ
Figure 8-15.
Figure 8-13. Disconnecting Fuel Line.
Figure 8-14. Removing Carburetor.
Hose Clamp
Figure 8-15. Disconnecting Carburetor Linkage.
2. Slide carburetor to the end of the intake studs.
See Figure 8-14.
Heat Shield
Head Spacer
Spacer Gasket
Throttle Lever
Rod Linkage
Spring Linkage

Kohler Courage XT-6 Specifications

General

Displacement	149 cc
Compression Ratio	8.5:1
Fuel Type	Unleaded gasoline
Starter Type	Recoil
Engine Type	4-Cycle, OHV, Single Cylinder
Oil Capacity	0.6 L (20 fl. oz.)
Ignition System	Electronic
Fuel Tank Capacity	1.1 L (37 fl. oz.)
