4 — PROGRAMMABLE PARAMETERS
Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022 Return to TOC
pg. 120
CONTROLLER SETUP — INPUTS MENU, cont’d
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Percent
Analog_Input_Percent_19
0x3B63 0x00
0.0 – 100.0 %
0 – 1000
Read Only The percentage of the voltage at the input pin is based upon the
High and Low settings, i.e., the percent of:
[(analog_input_volts_19) – (analog_input_19_low)] /
[(analog_input_19_high) – (analog_input_19_low)]
Low
Analog_Input_19_Low
0x330B 0x00
0.0 – 11.0V
0 – 1100
0.0V The minimum input voltage before a fault is declared. When the
Analog 19 Type selection is Voltage with Supply, this set point
represents the 0% point for the normalized input.
Faults:
When the voltage falls below this parameter, it will trigger
the Analog_19_OUT_OF_RANGE fault (flash code 0xBE, CAN
Index 0x262C).
If assigning the Throttle to Analog 19, the resulting fault will
become the Throttle Input fault (flash code 0x42, CAN Index
0x2210) if Throttle_Source = 19.
If assigning the Brake to Analog 19, the resulting fault will become
the Brake Input fault (Flash code 0x44) if Brake_Source = 19.
High
Analog_Input_19_High
0x330C 0x00
0.0 – 11.0V
0 – 110
11.0V The maximum input voltage before a fault is declared. When the
Analog 19 Type selection is Voltage with Supply, this set point
represents the 100% point for the normalized input.
Faults:
When the voltage rises above this parameter, it will trigger
the Analog_19_OUT_OF_RANGE fault (flash code 0xBE, CAN
Index 0x262C).
If assigning the Throttle to Analog 19, the resulting fault will
become the Throttle Input fault (flash code 0x42, CAN Index
0x2210) if Throttle_Source = 19.
If assigning the Brake to Analog 19, the resulting fault will become
the Brake Input fault (Flash code 0x44) if Brake_Source = 19.
Fault Tolerance
Analog_Input_19_Fault_
Tolerance
0x337B 0x00
0.0 – 11.0V
0 – 1100
0.0V Species the voltage threshold above the congured high limit
or below the low limit, exceeding this results in an analog out of
range fault.
For example, if High = 9.6V, Low = 1V and Tolerance = 0.2V, an
input voltage between 1V to 9.6V is mapped to 0–100%.
Voltages above 9.8V (9.6 + 0.2) or below 0.8V (1V – 0.2V) trigger
the fault.
Analog 31 menu
Voltage
Analog_Input_Volts_31
0x3B56 0x00
–327.68 – 327.67V
–32768 – 32767
Read Only Voltage at pin 26 (as the +5V External Supply in Fig 13).
Percent
Analog_Input_Percent_31
0x3B6B 0x00
0.0 – 100.0 %
0 – 1000
Read Only Voltage on a 0-100 percentage basis.
The percentage of the voltage at the input pin based upon the
High and Low settings, i.e., the percent of:
[(analog_input_volts_31) – (analog_input_31_low)] /
[(analog_input_31_high) – (analog_input_31_low)]
Low
Analog_Input_31_Low
0x3305 0x00
0.0 – 11.0V
0 – 1100
0.0V The minimum input voltage before a fault is declared.
This voltage represents the 0% point for the normalized inputs.
High
Analog_Input_31_High
0x3304 0x00
0.0 – 11.0V
0 – 1100
7.0V The maximum input voltage before a fault is declared.
This voltage is the 100% point for the normalized inputs.
Fault Tolerance
Analog_Input_31_Fault_
Tolerance
0x33B7 0x00
0.0 – 11.0V
0 – 1100
0.0V Species the voltage threshold above the congured high limit
or below the low limit, exceeding this results in an analog out of
range fault.
For example, if High = 9.6V, Low = 1V and Tolerance = 0.2V, an
input voltage between 1V to 9.6V is mapped to 0–100%.
Voltages above 9.8V (9.6 + 0.2) or below 0.8V (1V – 0.2V) trigger
the fault.
