4 — PROGRAMMABLE PARAMETERS
pg. 123
Return to TOC Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022
SWITCH ASSIGNMENT MENU
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Interlock Input Source
Interlock_Input_Source
0x34B2 0x00
0 – 32
0 – 32
5
[PCF]
Interlock Switch Assignment. Select the digital input number that
will be used for the interlock.
The Interlock Input Source must be set to 0 to allow VCL control
of interlock.
KSI control can be accomplished by setting the input source to
switch 20 (Keyswitch Input).
Interlock Input Source
Redundant
Interlock_Input_Source_
Redundant
0x3E6F 0x00
0 – 32
0 – 32
0
[PCF]
Selects the redundant Interlock Switch input source.
Forward Input Source
Forward_Input_Source
0x3342 0x00
0 – 32
0 – 32
0
[PCF]
Forward switch assignment.
Using the available switch inputs, select the digital input number
that the forward input signal will use. The available switches
depends upon the controller and application.
Reverse Input Source
Reverse_Input_Source
0x3344 0x00
0 – 32
0 – 32
0
[PCF]
Reverse switch assignment.
Using the available switch inputs, select the digital input number
that the reverse input signal will use. The available switches
depends upon the controller and application.
EMR Switch Source NO
EMR_Input_Source
0x3729 0x00
0 – 32
0 – 32
0
[PCF]
Sets a normally open EMR input.
When both this and the redundant EMR NC (0x372F) parameter
are unmapped, the EMR is settable by VCL. When both are
mapped, inputs are supervised to verify they remain in
complementary states.
EMR Switch Source NC
EMR_Input_Source_Redundant
0x372F 0x00
0 – 32
0 – 32
0
[PCF]
Sets a normally closed EMR input. When both this and the EMR
NO (0x3729) parameters are unmapped, the EMR is settable by
VCL.
Lift Input Source
Lift_Input_Source
0x372A 0x00
0 – 32
0 – 32
0
[PCF]
Select which input # to use as Lift source.
Requires a key cycle to take effect. Requires further input
mapping setup. See Hydraulics menu.
0: VCL Throttle (range: 0-100)
1–32: Input Number.
Lower Input Source
Lower_Input_Source
0x372B 0x00
0 – 32
0 – 32
0
[PCF]
Select which input # to use as Lower source.
Requires a key cycle to take effect. Requires further input
mapping. See Hydraulics menu.
0: VCL Throttle (range: 0-100)
1–32: Input Number.
Tow Input Source
Tow_Input_Source
0x33B8 0x00
0 – 32
0 – 32
0
[PCF]
Selects which input number to use as the Tow Mode.
Contact Curtis BEFORE using this option.
Both ACIM and PMAC motors behave differently and require
strict parameter settings to prevent controller damage.
NOTICE
