4 — PROGRAMMABLE PARAMETERS
Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022 Return to TOC
pg. 124
CONTROLLER SETUP/IO ASSIGNMENTS — SWITCH STATUS MENU
PARAMETER ALLOWABLE RANGE DEFAULT
DESCRIPTION
MONITORS THE CONTROLLER SWITCH STATUS
Switch 1
Switch_1
0x3324 0x00
On/Off
On/Off
Read Only Pin 16 (35 pin controllers).
Pin 11 (23 pin controllers).
Switch 2
Switch_2
0x3325 0x00
On/Off
On/Off
Read Only Pin 8 (normally = Motor Temp sensor input) (35 pin controllers).
Pin 9 (normally = Motor Temp sensor input) (23 pin controllers).
Switch 3
Switch_3
0x3326 0x00
On/Off
On/Off
Read Only Pin 31 (normally = Encoder A input) (35 pin controllers).
Pin 17 (normally = Encoder A input) (23 pin controllers).
Switch 4
Switch_4
0x3327 0x00
On/Off
On/Off
Read Only Pin 32 (normally = Encoder B input) (35 pin controllers).
Pin 18 (normally = Encoder B input) (23 pin controllers).
Switch 5
Switch_5
0x3328 0x00
On/Off
On/Off
Read Only Pin 9 (35 pin controllers).
Pin 8 (23 pin controllers).
Switch 6
Switch_6
0x3329 0x00
On/Off
On/Off
Read Only Pin 15 (35 pin controllers).
Pin 10 (23 pin controllers).
Switch 7
Switch_7
0x332A 0x00
On/Off
On/Off
Read Only Pin 22 (35 pin controllers).
Pin 14 (23 pin controllers).
Switch 8
Switch_8
0x332B 0x00
On/Off
On/Off
Read Only Pin 33 (35 pin controllers).
Pin 15 (23 pin controllers).
Switch 9
Switch_9
0x332C 0x00
On/Off
On/Off
Read Only Pin 24 (35 pin controllers).
Not available/dened for 23 pin controllers.
Switch 10
Switch_10
0x332D 0x00
On/Off
On/Off
Read Only Pin 10 (35 pin controllers).
Not available/dened for 23 pin controllers.
Switch 11
Switch_11
0x332E 0x00
On/Off
On/Off
Read Only Pin 11 (35 pin controllers).
Pin 19 (23 pin controllers).
Switch 12
Switch_12
0x332F 0x00
On/Off
On/Off
Read Only Pin 12 (35 pin controllers).
Pin 21 (23 pin controllers).
CONTROLLER SETUP/IO ASSIGNMENTS — SWITCH STATUS MENU
e read only switch inputs On/O status include the inputs on any pins that can process a voltage
reading. Use the on/o status in this menu during setup and application development to verify an
“input” status. e 35-pin and 23-pin controllers have dierent pin number assignments. Reference
the wiring diagrams and I/O tables for the AMPSEAL pin number aligned to the switches.
e On/O (1/0) indicates the state of the binary input. e same value is encoded bitwise in the
variable Switches (variable 0x3321) which contains the state of all 32 Switches as applicable to the
controller. For the variable Switches, Switch_1 corresponds to bit position 0 (LSB), and Switch_32
corresponds to bit position 31 (MSB).
