4 — PROGRAMMABLE PARAMETERS
pg. 125
Return to TOC Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022
CONTROLLER SETUP/IO ASSIGNMENTS — SWITCH STATUS MENU, cont’d
PARAMETER ALLOWABLE RANGE DEFAULT
DESCRIPTION
MONITORS THE CONTROLLER SWITCH STATUS
Switch 13
Switch_13
0x3330 0x00
On/Off
On/Off
Read Only Pin 14 (35 pin controllers).
Pin 22 (23 pin controllers).
Switch 14
Switch_14
0x3331 0x00
On/Off
On/Off
Read Only Pin 25 (35 pin controllers).
Pin 23 (23 pin controllers).
Switch 18
Switch_18
0x333D 0x00
On/Off
On/Off
Read Only Pin 17 (35 pin controllers).
Not available/dened for 23 pin controllers.
Switch 19
Switch_19
0x333E 0x00
On/Off
On/Off
Read Only Pin 27 (35 pin controllers).
Not available/dened for 23 pin controllers.
Switch 20
Switch_20
0x3339 0x00
On/Off
On/Off
Read Only Pin 1 (the keyswitch, always = On when powered).
35 and 23 pin controllers.
Switch 21
Switch_21
0x3332 0x00
On/Off
On/Off
Read Only Pin 2 (when the driver is used as a switch input. 35 pin controllers).
Pin 7 (when the driver-1 is used as a switch input
23-pin controllers).
Switch 22
Switch_22
0x3333 0x00
On/Off
On/Off
Read Only Pin 5 (when the driver is used as a switch input 35 pin).
Pin 4 (when the driver-2 is used as a switch input
23-pin controllers).
Switch 23
Switch_23
0x3334 0x00
On/Off
On/Off
Read Only Pin 4 (when the driver is used as a switch input 35 pin).
Pin 5 (when the driver-3 is used as a switch input
23-pin controllers).
Switch 24
Switch_24
0x3335 0x00
On/Off
On/Off
Read Only Pin 3 (when the driver is used as a switch input 35 pin).
Pin 6 (when the driver-4 is used as a switch input
23-pin controllers).
Switch 25
Switch_25
0x3336 0x00
On/Off
On/Off
Read Only Pin 6 (when the driver is used as a switch input 35 pin).
Pin 3 (when the driver-5 is used as a switch input
23-pin controllers).
Switch 26
Switch_26
0x3337 0x00
On/Off
On/Off
Read Only Pin 19 (when the driver is used as a switch input. 35 pin controllers).
Not available/dened for 23 pin controllers.
Switch 27
Switch_27
0x3338 0x00
On/Off
On/Off
Read Only Pin 20 (when the driver is used as a switch input. 35 pin).
Not available/dened for 23 pin controllers.
