Section 7 Decision-Makerr 6000 Controller TP-6356 4/12
Calibration
User-Defined
Settings
Default SelectionRange SettingDigital Display
Refer
to
Menu
kW sharing gain 17 KW SHARING GAIN 0--99.99 1.00
kW sharing reset 17 KW SHARING RESET 0--50 sec. 50 sec.
kW sharing deadband 17 KW SHARING DB 0--10% 1.0%
Frequency trim gain 17 FREQ TRIM GAIN 0--99.99 1.00
Frequency trim deadband 17 FREQ TRIM DB 0--10% 0.1%
kW base load adjustment 17 KW BASELOAD ADJ 0--100% 50.0%
kW base load gain 17 KW BASELOAD GAIN 0--99.99 1.00
kW baseload reset 17 KW BASELOAD RESET 0--50 sec. 1.0 sec.
kW base load deadband 17 KW BASELOAD DB 0--10% 1.0%
% droop at rated kW 17 % DROOP AT RATED KW 0--10% 5.0%
% kW ramp rate 17 %KWRAMPRATE 0--25%/S 10.0%/sec.
% kW up/down rate 17 % KW UP/DOWN RATE 0--25%/sec. 1.0%/sec.
Disconnect 17 DISCONNECT 0--25% 5.0%
kVAR sharing gain 17 KVAR SHARING GAIN 0--99.99 1.00
kVAR sharing reset 17 KVAR SHARING RESET 0--50 sec. 1.0 sec.
kVAR share deadband 17 KVAR SHARE DEADBAND 0--10% 1.0%
Voltage trim gain 17 VOL TAGE TRIM GAIN 0--99.99 1.00
Voltage trim deadband 17 VOLT TRIM DEADBAND 0--10% 1.0%
kVAR base load 17 KVAR BASELOAD 0--100% 50.0%
Generate kVAR? 17 GENERATE KVAR? Generate/absorb Generate
kVAR base load gain 17 KVAR BASELOAD GAIN 0--99.99 1.00
kVAR base load reset 17 KVAR BASELOAD RESET 0--50 sec. 1.0 sec.
kVAR base load deadband 17 KVAR BASE DEADBAND 0--10% 1.0%
kVAR up/down rate 17 KVAR UP/DOWN RATE 0--100% 1.0%/sec.
Power factor setting 17 PF SETTING 0.50--1.00 PF 0.80 PF
Lagging power factor? 17 LAGGING PF? Lagging/leading Lagging
Power factor control gain 17 PF CONTROL GAIN 0--99.99 1.00
Power factor control reset 17 PF CONTROL RESET 0--50 sec. 1.0 sec.
Power factor control
deadband
17 PF CONTROL DEADBAND 0--0.1 PF 0.01 PF
Power factor up/down rate 17 PF UP/DOWN RATE 0--0.1 PF/S 0.001 PF/S
% voltage droop at rated
load
17 % VOLTAGE DROOP AT
RATED LOAD
0--20% 4.0%
Breaker energize time delay 17 BREAKER ENERGIZE TD 0.1--10.00 sec. 0.5 sec.
Breaker reclose time delay 17 BREAKER RECLOSE TD 0.5--30.00 sec. 2.0 sec.
Breaker close attempts 17 BREAKER CLOSE
ATTEMPTS
1--100 3
Circuit breaker current fault
limit
17 CB CRNT FAULT LIMIT 1--50% 5.0%
Circuit breaker current fault
time delay
17 CB CRNT FAULT TD 0--60 sec. 5.0 sec.
Transformer phase shift 17 XFMR PHASE SHIFT Fixed 0.00 deg.
