24 Section 1 Specifications TP-6356 4/12
1.10 Decision-Makerr 6000 with
Integral Voltage Regulator
1.10.1 Features
D A digital display and keypad provide access to data.
A two- line vacuum fluorescent display provides
complete and concise information.
D The controller provides built-in paralleling capabilities
for paralleling applications incorporating multiple
generator set and/or utility feeds.
D The controller can communicate with a personal
computer directly or on a network. See spec sheet
G6-76, Monitor III Software for more information.
D Using optional menu-driven, Windowsr-based PC
software, an operator can monitor engine and
alternator parameters and also provide control
capability.
D The controller supports Modbusr RTU (Remote
Terminal Unit), an industry standard open
communication protocol.
Voltage Regulator Menu 11 Displays
D Voltage adjust
d Three-phase voltage display
d Numeric entry of voltage adjust
D Under frequency unload (V/Hz) settings
d Enable/disable
d Cut-in frequency
d Numeric entry of V/Hz slope
D Reactive droop settings
d Enable/disable
d Numeric entry of droop setting
D Voltage regulator gain
D Analog voltage adjust enable
Paralleling Menu 16 Displays
D DPS system commissioning setup
d Node ID
d Number of nodes
D Synchronizing parameters setup
d Voltage matching
d Frequency matching
d Phase matching
d Time delays
D Synchronizing value metering
d Phase rotation
d Bus and generator voltages
d Bus and generator frequencies
d Phase difference
d Speed and voltage bias output values
D DPS system controls configuration
d Select digital inputs or software overrides
Load Share Control Menu 17 Displays
D Real power sharing and control setup
d kW sharing settings
d kW base load settings
d kW droop settings
d kW ramp settings
d kW disconnect level
D Reactive load sharing and control setup
d kVAR sharing settings
d kVAR control settings
d Power factor control settings
d Reactive droop settings
D Circuit breaker control setup
d Energize time
d Reclose time delay
d Maximum close attempts
d Fault current settings (fail to open)
Modbusr is a registered trademark of Schneider Electric.
Windowsr is a registered trademark of Microsoft Corporation.
1.10.2 Specifications
Specifications/
Features
Voltage Regulator Type
Integral with DEC 6000
Generator Set Availability 20--3250 kW
Type Microprocessor based
Status and Shutdown
Indicators
LEDs and Digital Display
Operating Temperature
-- 4 0 _Cto70_C(--40_F to 158_F)
Storage Temperature
-- 4 0 _Cto85_C(--40_F to 185_F)
Humidity 5--95% Non-Condensing
Circuit Protection
Solid-State, Redundant Software and
Fuses
Sensing, Nominal 100--240 Volts (L-N), 50--60 Hz
Sensing Mode RMS, Single- or 3-Phase
Input Requirements 8--36 VDC
Continuous Output 100 mA at 12 VDC
Maximum Output 100 mA at 12 VDC
Transition Frequency 50--70 Hz
No-Load to Full-Load
Voltage Regulation
±0.25%
Thermal Drift
<0.5%
(--40_Cto70_C)
[--40_F to 158_F] Range
Response Time Less Than 5μS
System Voltage Adjust. ±10%
Voltage Adjustment Controller Keypad
Remote Voltage
Adjustment
Digital Input Standard/
Analog 0--5 VDC Input Optional
Paralleling Capability
Reactive Droop plus Full Load Share
and Control
VAR/PF Control Input Standard
