Fig.#19
Installation steps Public anti-loss installation
Screw
Hook board
Expansion
pipe
Expansion bolt
Remove silicon plug
Remove silicon plug
Hook
Remote
Docking station
Seat gasket
Fig.#20
Installation of remote controller holder
NOTE: If the wall for installation is made of special material (such as wood board, density board and etc.)，proper
fixing methods shall be adopted.
NOTE: The place to install the remote controller shall not be easily splashed by water.
Choose a mounting location for the remote holder that is easily accessible while sitting on the seat.
Drilling two holes with depth larger than 45mm on the wall by drill with a diameter of 6mm in accordance with the
position of screw holes on the remote control holder, and then installs the expansion tube into the holes.
Place the installation holder on the fixing hole；
Peel off the release paper of double-sided tape at the back of holder；
Fix the holder with screws and install it.
Install the screw covers on the screws；
Place the remote controller on the holder.
