Dimension drawing
Unit: mm
Finished wall
400
300
Power receptacle
Water inlet
Finished floor
Kohler reserves the right to change marked dimensions without prior notice.
*
Power value testing condition: dynamic pressure 0.2Mpa, inlet water temp 15°C.
SPECIFICATIONS
Water supply volume
Water efficiency grade
Pit distance
Water pressure
Rated voltage
Rated power
Max instantaneous power
Length of power line
Product outline dimension
Weight of product
Inlet water temp
Operation Environment
NOTE: refer to "Homeowner's Guide" for detailed specifications of the bidet seat.
3.0Average 3.3L, Full flush 3.8L, Flush ECO L
Level I
Floor drain 305/400mm, wall drain (Refer to product configuration table)
Min water pressure 0.07Mpa (dynamic pressure)
Max water pressure 0.74Mpa
220V~，50Hz
1080W
About 1600W
About 1.5m
About 700mm X 418mm X 523mm
About 46kg
1-35℃
1-40℃
