Kohler EIR User Manual

3/8
10mm
Unit: mm
Fig.#10
Fig.#8
D. Drill 5 holes and insert plastic inserts and T-bolts (Purchased by customer).
400±10
300±10
300±5
150±5
150±5
300±5
130±5
Rough-in distance
130±5
L
Water inlet (G1/2 ID)
Bowl mounting holes
Discharge pipe mounting holes
Rough-in distance
150±10
300±10
135±5
135±5
L
C. 1. Confirm the drain holes center and mark “+” centerline.
2.2.
Mark discharge pipe mounting hole position as show.
3.3.
Mark bowl mounting holes as show.
Kohler Co.
7
1366733-T01-D
