Steam Hardware Locations (cont.)
Determine the location of the control kit and steam head based on the roughing-in dimensions
illustrated. Dimensions given in the rough-in information are crucial for proper installation.
Locate the control kit and steam head in the location indicated. All measurements are from the
inside of the module.
1045320-2-E 4 Kohler Co.
