Kohler KD2000 User Manual

TP-7070 7/18 63Section 2 Operation
Type Enter on screen keypad Enter on external keypad Complete write access
examples
Logic input variable %I I I0.0.0
Analog input variable %I I I5.21
Internal variable (input or
output)
%M M
M3.112
M1.0
M1.1
Logic output variable %Q Q Q0.0.0
Analog output variable %Q Q
Figure 2-69 Sample Variable Identification
Refer to the example in Figure 2-68 and the variables listed in Figure 2 -70. Other variables and events are shown in
Sections 2.9.4 and 2.10.
Title Color Name State or value
%M3.112 Green Low engine coolant warning 1
%I5.21 Fuel level 4
%M1.0 Red Auto mode 0
%M1.1 Green Manual mode 1
%I0.0.0 Red Input #0 (base module) 0
%Q0.0.0 Red Output #0 (base module) 0
Figure 2-70 Sample Variables Shown in Figure 2-68
