Kohler KD350 - Tank; Fuel Filter Kd 225-400-440 (Version With Internal Filter); Fuel Filter For Kd 225 - 315 - 350 - 400 - 440 (Version With External Filter)

14
16 17
15
8
- 25 -
DISASSEMBLY/REASSEMBLY
Toavoidexplosionsorre outbreaks,donotsmokeorusena-
kedamesduringtheoperations.
Fuelvapoursarehighlytoxic.Onlycarryouttheoperationsout-
doorsorinawellventilatedplace.
Keepyourfacewellawayfromthe plug to prevent harmfulva-
poursfrombeinginhaled.Disposeoffuelinthecorrectwayand
donotlitterasitishighlypolluting.
Tank
Unscrewtheupper andlowerstuds and removethewashers, which
otherwise might make removal of the tank difcult. Next disconnect
thefuelandairbleedingtubes.
Completelyemptythetanktomakesurethatnoimpuritiesremain.
Whenreassemblingtightentheuppernutsto15Nm.
1Fuellter
2Fueltank
3Filtersleeve
4Filtercartridge
5Flushring
6Nut
7Unionseal
8Dieselfueloutletunion
9Flatwasher
Seepage18forthefrequencywithwhichthefuelltermustberepla-
ced.
Seeg.99forthedimensions.
Loosentheclampsanddisconnectthehoses.
Characteristics
Filteringarea≥390cm
2
Paperporosity≤7µm.
Seepage18forreplacement
Seeg.98fordimensions.
KD 225_315_350_400_440 Workshop Manual_cod. ED0053029330_1° ed_ rev.00
Fuel lter for KD 225 - 315 - 350 - 400 - 440 (version with external lter)
Fuel lter KD 225-400-440 (version with internal lter)
