DISASSEMBLY/REASSEMBLY
Valves, characteristics
IntakevalveA
ExhaustvalveB-Stemandheadareoftwodifferentmaterials
Valves, guides and housings
1 Intakeguide
2 Exhaustguide
A=40
B=31
C=11.000-11.018
D =11.040-11.055
A=35
B=30
C=10.000-10.020
D =10.040-10.055
Note: Valve guides with outer diameters increased by 0.5 mm are
also available as spares. In this case, housing C must be in-
creasedby0.5mmforassemblypurposes.
Valves, guide insertion
Heattheblocktoatemperatureof160°-180°
Forcetheguides,consideringdistance Aand Binrelationtotheblock
surface.
A=25.8-26.2
B=34.8-35.2
A=23.8-24.2
B=28.8-29.2
WeldJoint
ChromePlated
ChromePlated
BaseMaterial
BaseMaterial
BaseMaterial
KD 225_315_350_400_440 Workshop Manual_cod. ED0053029330_1° ed_ rev.00
Dimensions (mm) for KD 315-350-400-440
Dimensions (mm) for KD 225
Dimensions (mm) for KD 315-350-400-440
Dimensions (mm) for KD 225
