DISASSEMBLY/REASSEMBLY
Valves - Disassembly
Components:
1Valvestem
2 Oilseal
3Springwasher/set
4 Spring
5Cap
6 Halfcollets
Note: To remove half collets place a suitable plate under the valve
headandpressdownrmlyasindicatedinthegure.
Valves - Oil seal in valve guide
To prevent seal 2 from being deformed when the valve guide is
mounted,titintotool1serialN°7107-1460-047afterhavingthorou-
ghlylubricatedit,thenproceedasindicatedinthegure.
Valve, springs
Measurethefreelengthwithacaliper.
FreelengthA =33.72
FreelengthA =34,88
Note:ReplacethespringifthefreelengthA is1mmlessthanspeci-
ed.
