TP-7070 7/1828 Section 2 Operation
2.7.3 Generator View
The generator view displays engine mechanical data and alternator electrical data. When in manual mode, the Engine
Start button also appears. See Figure 2-7.
1
1. Engine start appears in Manual mode only
2. Engine and mechanical view
3. Alternator electrical view
2
3
Figure 2-7 Generator View
