Kohler PRO 2.0 iS

KohlerPower.com29 33 590 03
4
3
7DK-053
5
6
7DK-054
a
760-001a
Spark plug inspection
The spark plug is an important engine component,
which should be checked periodically.
1. Remove the screws, and then remove the cover.
1 Screw
2 Cover
2. Remove the spark plug cap and cap, and insert
the tool through the hole from the outside of the
cover.
3 Spark plug cap
4 Cap
3. Insert the handlebar into the tool and turn it coun-
terclockwise to remove the spark plug.
5 Tool
6 Handlebar
4. Check for discoloration and remove the carbon.
The porcelain insulator around the center elec-
trode of spark plug should be a medium-to-light
tan color.
1
2
7PB-030
5. Check the spark plug type and gap.
a Spark plug gap
TIP
The spark plug gap should be measured with a wire
thickness gauge and, if necessary, adjusted to specifi-
cation.
Standard spark plug:
33 132 02-S (Kohler)
Spark plug gap:
0.6–0.7 mm (0.024–0.028 in)
