KohlerPower.com33 33 590 03
6. Insert the foam element into the air filter case.
NOTICE
The engine should never run without the foam ele-
ment; excessive piston and cylinder wear may
result.
TIP
Be sure the foam element sealing surface matches
the air filter so there is no air leak.
7. Install the air filter case cover in its original posi-
tion and tighten the screw.
8. Install the cover and tighten the screws.
AE01075
Muffler screen and spark arrester
The engine and muffler will be very hot after the
engine has been run.
Avoid touching the engine and muffler while they
are still hot with any part of your body or clothing
during inspection or repair.
1. Remove the muffler cover screws, and then
remove the muffler cover.
1 Muffler cover screw
2 Muffler cover
Recommended oil:
Foam-air-filter oil
or
engine oil (See page 15)
7PB-F8199-L2.indd 33 2014/01/08 17:07:38
