7
5. Cut the side channel sealing strip into two equal lengths. Remove the protective backing
and apply it to the back of the side channel starting just below the window panel frame.
Remove any excess length so that the seal is even with the bottom of the side channel.
Remove the Front Panel
1. Remove the four (4) screws from the front panel.
2. Press firmly on both sides of the metal case close to the front panel and pull the front panel
out and up to release it from the case.
3. Remove the four (4) screws on the front panel holding the control panel.
4. Be mindful of the control panel when moving the air conditioner.
