KOLDWAVE KOMPAC SERIES (KOOLETTE, KOMPAC, AND KING KOMPAC)
UNIT CONSTRUCTION
KOMPAC
Air Conditioner Cutaway
Control Panel Cutaway
Data
Name
Plate
Water
Fittings
Twin Wheel Plastic Casters
Thermostat
Knob
Front Air Discharge
Cooling Only Unit Shown
Blue Color Light
Fan
Speed
Switch
Cool/Fan/Off
Switch
Return
Air Louvers
Grille
Knob
(Spring
Retainer)
Controls
Back of Front Panel
High Pressure Control
Terminal Block
Run Capacitor
Suction and Discharge
Access Valves
Cabinet Insulation
Condenser Coil
Water Regulating
Valve
Thermostat
Sensing Bulb
