KOLDWAVE KOMPAC SERIES (KOOLETTE, KOMPAC, AND KING KOMPAC)
UNIT CONSTRUCTION
KOOLETTE
Air Conditioner Cutaway
Cooling Only Unit Shown
Thermostat
Knob
Blue Color Light
Fan
Speed
Switch
Cool/Fan/Off
Switch
Front Air Discharge
Return
Air Louvers
Grille
Knob
(Spring
Retainer)
Data
Name
Plate
Water
Fittings
Fan Housing
Fan Motor
Evaporator
Condensate Pump
Condensate Drain Pan
Condenser Coil
Suction and Discharge
Access Valves
Run Capacitor
High Pressure Control
Terminal Block
Water Regulating Valve
Compressor
Accumulator
