KOLDWAVE KOMPAC SERIES (KOOLETTE, KOMPAC, AND KING KOMPAC)
CAPACITY SELECTION
Koldwave Kompac Series Air Conditioners and Heat
Pumps are designed for any type of application with
cooling requirements ranging from 7,000 Btu/Hr with
the Koolette, 9,400 -16,000 Btu/Hr with the Kompac
and 20,500-26,000 Btu/Hr with the King Kompac. Also
heating requirements ranging from 7,800 Btu/Hr with
the Koolette, 10,900-17,900 Btu/Hr with the Kompac
and 24,000-31,000 Btu/Hr with the King Kompac. The
Kompac Series cooling capacity designations are
shown below.
Capacity Code:07 .................................. 7,000 Btu/Hr
10 .................................. 9,400 Btu/Hr
14 ................................ 12,500 Btu/Hr
16 ................................ 16,000 Btu/Hr
20 ................................ 20,500 Btu/Hr
26 ................................ 26,000 Btu/Hr
Kompac Model designations are:
Prefix K denotes....................Koldwave Kompac Model
Suffix D denotes....................... Air Conditioning Model
Suffix H denotes..........................................Heat Pump
Suffix T denotes ........ Unit for Cooling Tower Operation
Suffix S denotes ......................... Stainless Steel Finish
KOLDWAVE NOMENCLATURE
The Koldwave Kompac Series nomeclature is listed
below which explains the type of unit, the capacity, the
phase, and the voltage.
2 K 14 D H S T 1 1
Series 115 Volt
Koldwave Single Phase
Capacity Selection
Cooling Tower
Air Conditioning Model
Model
Heat Pump Option Type of Finish
Number Code: Phase: 1 - Single Ø
Voltage: 1 - 115V
2 - 208/230V
GENERAL REQUIREMENTS
For proper control of the water flow rate entering the
automatic water valve, the minimum water pressure
required for condenser water supply is 30 PSIG.
The condenser water temperature leaving the unit
should not exceed 110°F. Ignoring this compliance will
void the warranty on the refrigeration system. On heat
pump models, it is not recommended to operate the
unit in the heating cycle when the water inlet
temperature is below 50°F. Doing so could reduce the
specified heating capacity and may cause the freeze
control to cycle the compressor off, resulting in a loss
of heating.
IMPORTANT: Koldwave Air Conditioners have been
designed and engineered with your comfort in mind.
The length of service you can receive can be
extended by following the installation and
preventive maintenance instructions. It is important
that the warranty card be filled out completely and
returned to the factory within ten (10) days of
installation of the unit in order to receive the
benefits of the warranties.
