KOLDWAVE KOMPAC SERIES (KOOLETTE, KOMPAC, AND KING KOMPAC)
KOLDWAVE KOMPAC SERIES
SERVICE AND REPLACEMENT PARTS LIST
PART # DESCRIPTION K07 K10 K14 K16 K20 K26
STRAINERS
010-A-049 STRAINER 750171-1 XXXX
010-A-050 STRAINER 750011-6 XX
ASSEMBLIES,STRAINER & CAP TUBE
SA010-A-060 STRAINER & CAP TUBE ASSY. X
SA010-A-061 STRAINER & CAP TUBE ASSY. X X X
SA010-A-062 STRAINER & CAP TUBE ASSY. X
SA010-A-063 STRAINER & CAP TUBE ASSY. X
ACCUMULATORS
010-A-058 ACCUMULATOR 118001-03 X
010-A-052 ACCUMULATOR 137043-1 X X X
010-A-051 ACCUMULATOR 162032-1 XX
BLOWERS & BLOWER ACCESSORIES
013-D-090 BLOWER HOUSING 50-5R 1222
013-A-039 BLOWER HOUSING 60-6 22
013-A-040 BLOWER WHEEL CW 5/16" BORE S47-25/25 1
013-A-081 BLOWER WHEEL CW 1/2" BORE S47-25/25 1 1 1
013-A-082 BLOWER WHEEL CCW 1/2" BORE S47-25/25 1 1 1
013-A-041 BLOWER WHEEL CW 1/2" BORE S63-29/34 1 1
013-A-098 BLOWER WHEEL CCW 1/2" BORE S63-29/34 1 1
013-C-115 BLOWER RING 50-5R 2444
013-A-078 BLOWER RING 60-6 44
COMPRESSORS
020-A-178 1/2 HP 115V. AE233AT X
020-A-186 3/4 HP 115V. AK149BT X
020-A-213 3/4 HP 230V. AK149ET X
020-A-179 1HP 115V. AK144AT X
020-A-180 1HP 230V. AK144ET X
020-A-154 1-1/4 HP 115V. AK147AT X
020-A-155 1-1/4 HP 230V. AK147ET X
020-A-223 1-1/2 HP 230V. AW103FT X
020-A-224 2 HP 230V. AW105FT X
CASTERS
021-A-026 CASTER PPN-05748 BLACK XXXXX
ELECTRICAL COMPONENTS
025-A-691 SOLENOID COIL REV. VALVE L30-320
XXXX
115 V. HEAT PUMP
025-A-692 SOLENOID COIL REV. VALVE L30-420
XXXXX
230 V. HEAT PUMP
025-A-031 SERVICE CORD 115V. X
025-A-468 SERVICE CORD 115V. 15 AMP X X
025-A-469 SERVICE CORD 115V. 20 AMP X
025-A-470 SERVICE CORD 230V. 20 AMP XXXXX
025-A-608 ROCKER SWITCH TIGM721 COOL/OFF/FAN XXXXXX
025-A-609 ROCKER SWITCH TIGB51 LOW/HI XXXXXX
025-A-585 AMBER LIGHT 3LF4LAN1 115V. XXXX
025-A-610 AMBER LIGHT 3LF4LAN2 230V. XXXXX
025-A-621 BLUE LIGHT 3LF4LB21 115V. XXXX
025-A-622 BLUE LIGHT 3LF4LB22 230V. XXXXX
019-A-063 MOUNTING CLIP FOR INDICATOR LIGHT XXXXXX
FILTERS/AIR
030-A-034 9-1/8" x 15-3/4" x 1/2" X
030-A-041 15-7/8" x 18- 7/8" x 1/2" X X X
030-A-010 24" x 11-3/4" x 1/2" XX
EVAPORATORS
013-A-077 3 ROW #1557 X
031-A-092 3 ROW #1128 X
031-A-076 3 ROW #1522 X X
031-A-094 3 ROW #1186 X
031-A-127 4 ROW #2229 X
