Koldwave K6HK144BBA2ACA0 - Duct Connections

6 7
Owner’s Manual
K6HK144BBA2ACA0 / K6HK144BEA2ACA0
R
S
T
E
R
S
T
E
Figure 6
Figure 7
DUCT CONNECTIONS
Cool Air Out Duct(EVA)
Cool Air in Duct(EVA)
Hot Air Out Duct(COND)
Hot Air in Duct (COND)
Forkli
The Cool air duct connecons are labeled “AIR OUT”. The connecon size is
350Ø in diameter. Connect the exible air ducng as follows:
1. Aach the exible air ducng to the unit’s duct collars making sure
that air will not leak past the connecon collar by using appropriate
round exible ducng clamps.
2. Route the ducng as straight as possible to the space being
condioned avoiding excessive turns and pinches in the ducng.
3. Verify the terminaon points are not restricted meaning no
objects are directly in front of the terminaon.
The Return Air In duct connecon is labeled “AIR IN”.
The connecon size is 350Ø in diameter.
Follow the same procedures as the Cool Air Duct Connecons.
If you need outdoor air, please note that machine will read the
temperature of the outdoor air.
The Hot Air Out duct connecon is labeled “AIR OUT”
The connecon size is 450Ø in diameter.
Follow the procedures as the cool air duct connecons
The Hot Air Out duct connecon is labeled “AIR IN”
The connecon size is 450Ø in diameter.
Follow the procedures as the cool air duct connecons
If a forkli is needed to move the unit, put the foot of the forkli
to the forkli hole (shown in the picture: gure 8).
