KOLFF Black 3K - Connection and Operation Procedures; Pre-Connection Inspection; UPS Input and Output Connections

-11-
5. Connection and operation
5.1 Inspection:
Inspect the packaging carton and its contents for damage. Please
inform the transport agency immediately should you find signs of
damage.
Please keep the packaging in a safe place for future use.
Note: Please ensure that the incoming feeder is isolated and
secured to prevent it from being switched back on again.
5.2 Connection:
(1) UPS Input Connection
If the UPS is connected via the power cord, please use a proper
socket with protection against electric current, and pay attention to
the capacity of the socket: over 10A for 1K(S) & 2K, over 16A for
2KS& 3K(S).
(2) UPS Output Connection
The output of 1K(S), 2K are socket-types only. Simply plug the
load power cord to the output sockets to complete connection.
Model No. Output Socket (pcs) Terminal Block
1K/1KS 4 Nil
2K 6 Nil
2KS 4 Available
3K/3KS 4 Available
The system may be installed and wired only by qualified
electricians in accordance with a
pp
licable safet
y
re
g
ulations!
When installing the electrical wiring, please note the nominal
am
p
era
g
eof
y
our incomin
g
f
eede
r
.
