-14-
5.7 Audible Alarm Mute Function:
If the alarm is too annoying in battery mode, you may press “ON”
button continuously for more than 1 second to clear it. Moreover, the
alarm will be enabled when the battery is low to remind you to
shutdown the load soon.
5.8 Operation Procedure of External Battery for Long
Backup time Model (“S” Model)
The units with CE markings—
(1) Use the battery pack with voltage: 36VDC for 1KS (3 pcs of 12V
batteries), 96VDC for 2KS/ 3KS (8 pcs of 12V batteries).
Connection of batteries more than or less than required will cause
abnormality.
(2) One end of the external battery cord is a plug for connecting the
UPS and the other end has a plug for connecting the user battery
cabinet.
(3) Do not connect the UPS to any load yet. Then, connect the power
cord of the UPS to supply utility power to the UPS to make the
UPS operate in utility power mode.
(4) Connect the plug of the external battery cord to the external
battery socket on the rear panel of the UPS to complete the
connection procedure and the UPS will start to charge the battery
pack.
(5) The red wire is connected to the "+" terminal of the battery. The
black wire is connected to the "-" terminal of the battery. (Note: the
green/yellow wire is grounded for protection purpose.)
The Caution!
The output sockets of the UPS system may still be electrically live
even if the power supply system has been disconnected or the
Bypass switch is on “OFF” position.
