I.3 Abbreviations used in this manual
The table below explains the abbreviations which are used in this manual.
Abbrev. Meaning Abbrev. Meaning
AGND analog ground NSTOP limit-switch input for rot. dir. CCW
BTB
system ready PELV protected low voltage
CE European Community PGND ground for the interface used
CLK clock PSTOP limit-switch input for rot. dir. CW
DGND digital ground PWM pulse-width modulation
DIN German Standards Institute RAM memory component
EEPROM electrically erasable programmable ROM R
Ballast
ballast resistor
EMV electromagnetic compatibility RES resolver
EN European standard SPS programmable logic controller (PLC)
ESD electrostatic discharge SRAM static RAM
IDC analog current monitor SSI synchronous serial interface
IEC
International Electrotechnical
Commission
SW setpoint value
IGBT insulated-gate bipolar transistor V AC AC voltage
ISO
International Standardization
Organization
V DC DC voltage
INC incremental interface VDE
Association of German Electrical
Engineers
LED light-emitting diode VTA analog speed monitor
NI zero pulse XGND supply voltage ground
I.4 Nameplate
The nameplate depicted below is mounted on the servo amplifier. The information shown below
is printed in the individual sections.
PageI-2 General Chapter I
03.98 - A.4.028.6/10 digifas
®
7200 series
CONNECT module
and options
Serial numberServo amplifier type
Power supply
Installed load
Output current
in S1 mode
Software version
