EXPLANATION OF COMPONENTS OPERATION
3-46
OPENING AND CLOSING ENGINE SIDE COVER 3
When opening
Pull door release lever (1) to release the lock, then pull the
cover up.
When closing
NOTICE
When closing the cover, always release the gas damper lock first.
If the gas damper lock is not released and any attempt is made to close the cover, the gas damper may
break.
Push the orange button in the center of the gas damper (1) to
release the lock, then push the cover down.
ASHTRAY 3
This is on the left side of the operator's seat.
Always make sure that you extinguish the cigarette before clos-
ing the lid.
To Next Page
