FOREWORD INTENDED USE
1-9
VISIBILITY FROM OPERATOR'S SEAT 1
The visibility standards (ISO 5006) for this machine require a view shown in the diagram below.
PROXIMITY VISIBILITY 1
The figure bellows shows a front visibility from the machine at a spot 1.0 m away from the side and 1.5 m above
the ground. Shaded area (A) in the figure shows an area whose view is blocked by part of the machine. Operate
the machine, fully aware that the machine has a portion that an operator cannot see.
12M CIRCUMFERENCE VISIBILITY 1
The figure below shows a visibility from the machine within a circle of 12 m in radius. Shaded area (B) in the figure
shows an area whose view is blocked by part of the machine. Operate the machine, fully aware that the machine
has a portion that an operator cannot see.
