1. Introduction
The KOMTRAX is a system that operation status of the machine is automatically collected
and can be seen and controlled through Internet.
1.1. Formation of KOMTRAX
The KOMTRAX System consists as shown below:
(1) The KOMTRAX terminal continuously watches and measures conditions of the machine
on which it is incorporated.
(2) The measured data are sent out to the KOMTRAX Server (at Komatsu Computer Center)
via portable and wireless transmission channel every one hour.
(3) The data are accumulated and aggregated on the KOMTRAX Server.
(4) Operation conditions of the machine can be taken out in the form of tables and graphs
through the Internet.
Client's machine
Control panel
KOMTRAX
Terminal
External
antenna
KOMTRAX
Server
Portabl
e and wireless
transmission
Internet
Client's PC
* The PC for WEB browsing and Internet environment have to be prepared by the clients.
KOMATSU
Client's company
