29. INTRODUCTIONS OF ATTACHMENTS
Weight
(with side cutters)
No.
of teeth
Arm
1.8 m
(5’11'’)
2.4 m
(7’10'’)
2.93 m
(9'9”)
3 ❍❍❍
3❍❍❍
5❍❍❍
5jj!
6!!!
6!! x
29.2 ATTACHMENT INSTALLATION COMBINATION TABLE
PC210-6K, PC210LC-6K
This table lists the combination of attachments which can be installed to the standard short arms.
❍ Can be used for general digging.
! Can be used only for light-duty digging and loading work.
x Cannot be used.
Categories of use
For general digging : digging or loading sand, gravel, clay etc.
For light duty digging : digging or loading dry, uncaked earth and sand, mud etc.
For loading work : loading dry, loose earth and sand
• For digging or loading hard soil or soft rock, it is recommended that the strengthened bucket with high durabil-
ity and high wear resistance be employed
NOTICE
• When the extension arm is equipped, if the bucket is drawn tot the machine body, the arm interferes
with the body. Operate the extension arm carefully.
• When the boom is fully lowered during oblique digging, the boom interferes with the undercarriage.
Operate the boom carefully.
BUCKET AND ARM COMBINATION
0.71 m
3
0.65 m
3
900 mm 583 kg
1.08 m
3
0.96 m
3
1250 mm 713 kg
1.19 m
3
1.06 m
3
1350 mm 745 kg
0.45 m
3
0.41 m
3
650 mm 486 kg
0.87 m
3
0.78 m
3
1050 mm 631 kg
0.60 m
3
0.55 m
3
800 mm 552 kg
These charts are based on over-side stability with fully loaded bucket at
maximum reach.
A wide variety of buckets & attachments is available. Contact your local
dealer for more information.
❍ Material weight up to 1.8 t/m
3
(3030 lb/cu.yd).
j Material weight up to 1.5 t/m
3
(2530 lb/cu.yd).
! Material weight up to 1.2 t/m
3
(2020 lb/cu.yd).
x Not usable.
