TestingtheoperatingfunctionalityoftheST90
system
Topics
Measuringthenoisewiththetransducerdisconnected,page24
MeasuringtheB-ScannoisewiththetransducerdisconnectedfromtheTransceiverUnit,
page26
Testingtheuserinterfacetoverifybasicfunctionality,page28
Measuringthenoisewiththetransducerdisconnected
Lownoiseisakeyfactorforhighqualityandreliablemeasurements.Theperformanceof
theST90systemwillalwaysbelimitedbydifferentnoisesources.Ahighnoiselevelwill
masktheechoesandmakethemdifculttoreadandinterpret.Thenoiseismeasuredwhile
theST90systemoperatesinPassivemodewiththetransducerdisconnected.
Prerequisites
TheST90systemhasbeensetupwithitshardwareunitsconnectedasspeciedinthe
InstallationManual.ThehullunitandtheMotorControlUnitarereplacedwithahullunit
simulator.Thetransducerisreplacedwithadummyload.TheST90systemisturnedonand
operatesnormally.Neithertoolsnorinstrumentsarerequired.
Context
Thistaskallowsyoutocheckthenoiseconditions.Tomeasurethenoiselevel,observethe
valuepresentedontheNoisepageintheDiagnosticsdialogbox.
Note
Thistaskmustbedonewiththetransducercabledisconnectedfromthetransceiver .
Procedure
1OpentheOperationmenu.
2SetTxPowertoOff.
3Disconnectthedummyloadfromthetransceiveroutput.
4Makethefollowingpreparations.
