Kongsberg Simrad ST90 - Testing the User Interface to Verify Basic Functionality

28
442728/B
cSelectElementamplitude.
dSetStartsampleto:400
eSetSamplerangeto:10,000
6MakesurethatallthechannelsarepresentintheB-Scanpresentation.
7RecordthenoisevalueatthebottomoftheB-Scanpage.
8MakeascreencaptureoftheB-Scanpage,andsaveit.
Savethescreencaptureusingauniquelenamethatidentiescontext,date,time
andtherelevantserialnumber.
9Connectthedummyloadtothetransceiveroutput.
Result
Requirements
Results
Maximumnoiselevel(indB)shownontheB-Scanpagewhenthetransducerisdisconnectedmustbeless
than:-105
Maximumnoiselevel(indB)measuredontheB-Scanpage:
Screencapturesarerecordedandsaved.
Date/Signature:
Testingtheuserinterfacetoverifybasicfunctionality
AfunctionaltestisdonewiththeST90systemassembledasacompleteproduct.
Prerequisites
TheST90systemhasbeensetupwithitshardwareunitsconnectedasspeciedinthe
InstallationManual.
•Thetransducerisreplacedwithadummyload.
•ThehullunitandtheMotorControlUnitarereplacedwithahullunitsimulator.
•TheST90systemisturnedonandoperatesnormally.
SimradST90FactoryAcceptanceTest
