Konica Minolta BIZHUB 164 Service Manual

1
11. SERVICE MODE Field Service Ver. 2.0 Jun. 2010
112
bizhub 164
ADJUSTMENT / SETTING
11.7.3 TCR AUTO ADJUST
A. Use
•To make an automatic adjustment of the TCR sensor.
•Used at setup.
•Used when developer has been changed.
•Used when IU has been replaced.
B. Procedure
NOTE
• Before starting this adjustment, the toner bottle must be removed.
1. Press the Menu/Select key to start the adjustment.
2. The adjustment sequence automatically stops as soon as the adjustment is made,
and TCR gain value is displayed.
<Conversion formula of TCR gain value to voltage>
TCR control voltage (V) =3.3 x 2 x [TCR gain value] / 256
1

Konica Minolta BIZHUB 164 Specifications

General

Print Technology	Laser
Print Speed	16 ppm
Print Resolution	600 x 600 dpi
Copy Speed	16 cpm
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Paper Capacity	250 sheets
Interface	USB 2.0
Warm-up Time	29 seconds
Paper Input Capacity	250 sheets
Memory	32 MB
Type	Monochrome
Maximum Paper Size	A3
Duplex Printing	Manual
Network Connectivity	No
USB Connectivity	Yes
Paper Size	A5
Fax Resolution	Not applicable
