Before making copies
1
C451 1-10
32 Jack for connecting a telephone
(TEL PORT2)
Used for connecting the cord from a telephone.
33 Telephone jack 2
(LINE PORT2)
Used for connecting a general subscriber line.
This jack is used when the optional fax multi line is in-
stalled.
34 Jack for connecting a telephone
(TEL PORT1)
Used for connecting the cord from a telephone.
35 Telephone jack 1
(LINE PORT1)
Used for connecting a general subscriber line.
36 RS-232C port Used for connecting the JScribe IC card reader/writ-
er.
37 USB port (type A)
USB 2.0/1.1
Used for connecting the USB cable for the authenti-
cation unit (biometric type), the authentication unit
(IC card type) or external memory (USB memory).
38 External controller port Used for connecting the cable from the image con-
troller.
39 Internal controller port Used for connecting the internal controller.
40 USB port (type B)
USB 2.0/1.1
Used for making connections when the machine is
used as a USB printer.
41 RS-232 port Used for connecting the modem for CS Remote
Care.
42 Network connector
(10Base-T/100Base-TX/
1000Base-T)
Used for connecting the network cable when this
machine is used for network printing and network
scanning.
43 Ozone filter Collects the ozone generated in the machine.
No. Part name Description
