28 OPERATION MANUAL
SPECIFICATIONS
Model name : SRX-101A
Film transport method : Continuous roller transport.
Film type and sizes : Sheet film, 10 x 10 cm~ 14 x 17 inch(35 x 43 cm) sizes.
Processing capacity :
Process cycle switching : Available by a service engineer.
Processing solution volumes : DEV tank : 1.03 gallons
FIX tank : 0.47 gallons
WASH tank : 0.37 gallons
Temperature control : Processing solution temperature;
Controlled by the temperature control tank, with the thermistor monitoring,
and with the heater heating.
Drying temperature;
Controlled automatically according to a fixed temperature setting.
Replenishing system : Replenishing volume for the film sheet is calculated exchanging with
10"x12" film.
Circulation system : Continuous pumping of developer and fixer solutions.
Wash water : Ordinary tap water 41 ~ 86<
Water pressure 49 ~ 686 kPa(0.5 ~ 7kgf/cm
2
, 7 ~ 98psi)
Water supply : 0.22 gallons(0.8 liters)/min.
Standby functions : 10min./30min./Continuous operation. (Selectable by a service engineer)
Power source : AC 115/120V, single phase, 12A, 60 Hz.
Dimensions(W x D x H) : 24.0 x 26.8(35.4 incl. feed table) x 17.8 inch.
Weight : 40kg (47kg with processing tank full)
88 lb (104 lb with processing tank full)
Certification : Conforms to UL, FDA.
Applied standard : FCC
Heat generation : Approx.3135kJ/hr max.
Noise level : Approx.55dB(A) max.
Operating condition : 59 ~ 86<, 30 ~ 75%RH(no condensation)
Storage and transport condition : --4 ~ 140<, 20 ~ 95%RH(no condensation)
Accessories : Measuring cup, Funnel, Installation parts kit, Replacement parts kit,
Replenisher tanks, and Operation manual.
Optional equipment : Light shield panel, Stand, Splash guard.
*The above specifications are subject to change without prior notice.
Size
Cycle
10 x 12 inch 14 x 17 inch
90sec. 75 60
120sec. 70 55
180sec. 55 40
(sheets/hr)
