4
Camera:
1 Antenna
2 Camera bracket
3 5V DC power input
4 Pairing button
On front of the camera RED LED power ON
On front of the camera GREEN LED linked with receiver
Installation instructions:
1
2
3
4
To composite VIDEO input
Power ON
VIDEO output
cable
